✦ New ArrivalFeaturedPoE+ManagedGigabitNetworking
Cisco
Cisco CBS250 24-Port Gigabit PoE+ Smart Switch
24-port Gigabit PoE+ smart-managed switch.
Ports
24 Ă— 10/100/1000 Mbps + 4 Ă— SFP
PoE Standard
IEEE 802.3af / 802.3at (PoE+)
PoE Budget
195 W total
Switching Capacity
56 Gbps
Product Details
Overview
The Cisco CBS250-24P is a 24-port Gigabit Layer-2+ smart-managed switch built for dense IP-telephony, surveillance and access-point deployments. A 195 W PoE+ budget powers IP phones, Wi-Fi APs and IP cameras directly over the copper ports, removing the need for separate power injectors. Four Gigabit SFP uplinks enable fibre aggregation to the core, while VLANs, IGMP snooping, QoS and an intuitive web/CLI management plane give IT teams full control. The fanless 1U metal chassis stays silent and rack-friendly for wiring closets and small server rooms.
Key Features
195 W PoE+ budget powers phones, APs and cameras on every port
Four Gigabit SFP slots for fibre uplink and aggregation
Layer-2+ smart management: VLAN, QoS, IGMP snooping, LACP
Loop protection and storm control for a stable network
Fanless 1U metal chassis — silent, low-heat operation
Web GUI, CLI and SNMP for flexible remote administration
Specifications
9 specsPorts24 Ă— 10/100/1000 Mbps + 4 Ă— SFP
PoE StandardIEEE 802.3af / 802.3at (PoE+)
PoE Budget195 W total
Switching Capacity56 Gbps
Forwarding Rate41.66 Mpps
MAC Table16K entries
ManagementWeb GUI · CLI · SNMP v1/v2c/v3
Mounting1U 19" rack-mountable (fanless)
WarrantyLimited Lifetime
